SHE EM User Manual

11
02/13424999459
RWA Kettenantrieb EM/S/MKAZ/UL
V3
Montage am Kippfenster (Rahmenmontage)
1
2
Z
Y/1
Y/2
B
C
B
A
C
4
4.1
3
2
1
4.1
1
2
3
6
4
3
5
6
5
4
3
6
5
4
3
7.3 Kippfenster Rahmenmontage
10
15
30
15
15
15
15
19
12
15
12
19
SBEM-R0 SBEM-R10
SBEM-R15
X = 327 mm Hub: A = 592 mm
X = 419 mm Hub: A = 685 mm
X = 511, 603 mm Hub: A = 868 mm
X = 810 mm Hub: A = 1060 mm
B = 46 mm C = 0 mm (SBEM-R0)
C = 10 mm (SBEM-R10)
C = 15 mm (SBEM-R15)
X = 327 mm Hub:
Y/1 = Y/2 = 283,5 mm
Z = 567 mm
X = 419 mm Hub:
Y/1 = Y/2 = 329,5 mm
Z = 659 mm
X = 511, 603 mm Hub:
Y/1 = Y/2 = 421,5 mm
Z = 843 mm
X = 810 mm Hub:
Y/1 = Y/2 = 517,5 mm
Z = 1035 mm
