20
5-9 PV filter time setting screen
Initial value: 0 (seconds)
Setting range: 0–9999 (seconds)
Used to alleviate the effect if input varies radically or noise is
superimposed.
Filter does not function if set to 0 seconds.
5-10 Measuring range code setting screen
Initial value: Multi 05
Setting range: Selected from “7. Measuring range codes.”
Combination of input type and measuring range is set by the code.
Setting cannot be changed during control action
Note: Stop control action to change setting on 5-10–5-16 screen.
Changing the setting initializes related parameters, so the
parameters need to be reconfigured.
5-11 Input temperature unit setting screen
Initial value: c ()
Setting range: c, F ()
Temperature unit for sensor input is set to c (°C) or F (°F).
Not displayed if linear input (mV) is selected.
K () is displayed if measuring range code is 14–15 (in kelvin).
5-12 Input range lower limit value setting screen
Initial value: 0 (digit)
Setting range:
For linear range:
Selected from the input types shown in the measuring
range code table
Others:
Selected from the measuring ranges shown in the
measuring range code table
5-13 Input range higher limit value setting screen
Initial value: 1370
Setting range:
For linear range:
Selected from input types shown in the measuring
range code table
Others:
Selected from measuring ranges shown in the
measuring range code table
Setting the input range also limits the measuring range of
the selected range.
To 5-14 screen
5-14 Input scaling lower limit value setting screen
Initial value: 0 (digit)
Setting range: -1999–9989 (digit)
Sets scaling lower limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
5-15 Input scaling higher limit value setting screen
Initial value: 1370
Setting range: (Sc_L set value) + 10 to (Sc_L set value) + 10000
Sets scaling higher limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
5-16 Input decimal point position setting screen
Initial value: No decimal point (0)
Setting range:
For linear input:
No decimal point (0) to 3 digits following decimal
point (0.000)
Others:
No decimal point (0) to 1 digit following decimal
point (0.0)
Sets decimal point position for input scaling.
Range with no decimal point cannot be set by monitor alone.
5-17 Time unit setting screen
(Displayed only when programming function is selected)
Initial value: Hm ()
Setting range: Hm, mS ()
Sets time unit used by programming function.
Hm: Hour/minute, mS: Minute/second
5-18 FIX upon PROG end and setting screen
(Displayed only when programming function is selected)
Initial value: oFF
Setting range: oFF, oN
Sets whether to proceed to the FIX mode upon program completion.
To 5-0 screen
Range Measuring range Input range Actual measuring range Input scaling
hm 0–1370°C 10–1000°C 10–1000°C 10–1000°C
oj -10 mV–50 mV 0 mV–10 mV 0 mV–10 mV 0.0–10.0 mV
¦
h
|
hm
¦
h
¦
ikoh
h
¦
h
¦
ikoh
~
¦
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
Å
ģ
+
Å
