23
BT-E8020
•
This procedure is an example using a frame whose battery is removed/installed from below.
•
If using a battery cover manufactured by another company, remove the battery cover before removing the battery.
1.
Open the keyhole cap.
Turn off the power, then open the keyhole cap.
Push power button to turn off the power.
Key hole cap
2.
Unlock the battery.
(1) Insert the key into the key cylinder in the battery mount.
(2) Turn the key.
The battery is unlocked. The plate spring holds the battery in place, preventing it from falling out.
Key cylinder
Key
3.
Remove the battery.
(1) Remove the key, then close the keyhole cap.
(2) Remove the battery carefully.
To Next Page
