Shimano BeastMaster 9000 - Functions with Settings that Can Be Changed from the Menu; Auto Casting Function Settings; PGM (Program Mode) Activation

13
Casting (Auto Casting Function)
This function can be turned ON or OFF.
With auto casting, when lowering the rig, at 5m past the gunwale stop
position, the motor starts automatically, minimizing spool resistance.
(Example: If the gunwale stop position is 1m, the motor starts at 6m.)
PGM (Program Mode)
Turn this function ON or OFF. When set to ON, you can select an available movement
pattern or program/select your own pattern.
※
When Program Mode is ON, Pick Up Mode is automatically turned OFF.
See pages 50–57 for details.
Menu Screen
Scroll through the Menu list by moving the
cursor up or down.
The current setting appears to the right of the
function name.
(Settings shown here are for instructional
purposes only.)
After each function is set, the screen will return to the Menu Screen.
To return to the Water Depth Display, select RETURN from the Menu Screen and
press SET.
*When you change a setting from the default, the setting is saved even after the
power is turned off.
CurrentSetting
When you select a function on the Menu
Screen using the button operation shown
on the previous page and press SET, the
menu for the function or the settings
screen appears.
The items for which settings can be
changed for each function are shown at
right.
※
When Pick Up Mode is ON, Program Mode is automatically turned OFF.
(Defaultsetting:15)
Select
WhensettoON,
youareledto
thePickUpspeed
settingscreen
When set to ON, you can make adjustments from the Pick Up speed setting screen (above
right).
Use
▼▲
to increase or decrease the value to the speed you want, and press SET.
Setting the Pick Up Speed
PICK UP
This function can be turned ON or OFF.
When ON, the winding speed can be set from 0 to Hi.
Pickup
Auto Casting
Function
Functions with Settings that Can Be Changed from the Menu
(Continued on the next page.)
