Installation/removal
Installing the dual control lever
6. Connect the electric wire. If required, first remove the dummy plug of
the E-TUBE port.
Be sure to push it in firmly with the TL-EW300 until you feel a click.
For instructions on using the TL-EW300, refer to the ROAD Di2 Dealer's Manual General
Guide.
E-TUBE port ×2
Dummy plug
Electric wire
NOTICE
• It is possible for the electric wires to become disconnected accidentally while
riding or winding the handlebar tape. By allowing sufficient wire length,
accidental disconnection can be prevented after winding the handlebar tape.
• Ensure that the electric wire to connect to the dual control levers has extra
length to make it easier to remove and insert when performing maintenance.
