18
Installation/removal
Installing the brake cable
NOTICE
• When inserting the outer casing, take care to ensure that the tip of the outer
cap with tongue is not damaged.
• When using the BC-1051 inner cable, use a regular outer cap rather than an
outer cap with tongue.
Installing the brake cable
1. Depress the brake lever and insert the brake cable.
Pass the brake cable through the outer casing and install it to the lever as shown in the
figure.
Outer casing
Inner end
Cable hook
