36
Installation/removal
Installing the brake caliper
3. Secure the brake caliper to the frame base.
5 - 7 N·m
Brake fixing screw
4. Remove the protection sheet.
Installing the brake caliper (BR-RS811-R)
1. Temporarily install the brake caliper to the frame base.
Install it together with the assembly tool.
Brake fixing screw
0.5 N·m
