Maintenance
Brake shoe characteristics
WARNING
• Make sure to use the dedicated brake shoe for the shoe holder of the BR-R9210-F
/ BR-R8110-F / BR-RS811-R. Other models of brake shoes have different fixing
positions preventing the fixing screw from being tightened, which will cause the
brake shoe to come off and disable braking.
Dedicated brake shoes:
R55C4 / R55C4 (for carbon rim) / R55C4-A (for carbon rim) / R55CT4
Brake shoe characteristics
The specifications of the brake shoes are subject to change for product improvement.
Model No. R55C4 R55C4 for carbon
rim
R55C4-A for
carbon rim
Brake shoe shape
Cartridge type
X X X
Recommended rim
Aluminum Carbon Carbon
Characteristics
DRY Power
WET Power
Silence
Anti-fading
Durability (on-road)
Durability (muddy
conditions)
Anti-rim attack
Model No. R55C3 R55C+1 R55CT4
Brake shoe shape
R55C3
R
FORWARD
R55C3
R
FORWARD
