Installation/removal
Securing the BC-9000 cable
5. After depressing the brake lever several times, there may be a change
in the shoe clearance. If necessary, adjust the shoe clearance again to
be the same on the left and right (1.5 - 2 mm).
Adjust the shoe clearance to be the same on the left and right (1.5 - 2 mm).
BR-R9200 / BR-R9210-F / BR-R9210-RS /
BR-R8100 / BR-R8110-F / BR-R8110-RS
BR-RS811-R
Shoe clearance
Shoe clearance
Cable adjustment nut
Self-locking nut
6. Depress the brake lever until it touches the grip about ten times to
re-check shoe clearance and each component for any abnormalities.
