Maintenance
Replacing the bracket cover
4. Install a new bracket cover.
Insert the protrusions on the bracket cover into the recesses in the bracket body when
fitting on the bracket cover.
The inside of the bracket cover has a mark indicating the left side or right side.
Bracket cover
TECH TIPS
• It is easier to perform installation if isopropyl alcohol is applied to the inside of
the bracket cover.
5. Reinstall the dual control levers.
(1) Install the dual control levers to the handlebar.
(2) Install the electric wire and brake cable to the dual control lever.
