Decimal point place selection
No decimal point
• Selects decimal point place.
• Available only for DC inputs
• : No decimal point : 1 digit after decimal point
: 2 digits after decimal point : 3 digits after decimal point
PV filter time constant setting
0.0 seconds
• Sets PV filter time constant. (If the value is set too large, it affects control result due to
the delay of response)
• Setting range: 0.0 to 10.0 seconds
OUT1 high limit setting
100%
• Sets the high limit value of OUT1.
• Not available if OUT1 is in ON/OFF action
• Setting range: OUT1 low limit value to 100%
(DC current output type: OUT1 low limit value to 105%)
OUT1 low limit setting
0%
• Sets the low limit value of OUT1.
Not available if OUT1 is in ON/OFF action.
• Setting range: 0% to OUT1 high limit value
(DC current output type: –5% to OUT1 high limit value)
OUT1 ON/OFF action hysteresis setting
1.0
• Sets ON/OFF action hysteresis for OUT1.
• Available only when OUT1 is in ON/OFF action
• Setting range: 0.1 to 100.0 ( ), or 1 to 1000
OUT2 action mode selection
Air cooling
• Selects OUT2 action from air, oil and water cooling.
• Not available if the DT option is not added or if OUT2 is in ON/OFF action
• : Air cooling, : Oil cooling, : Water cooling
OUT2 high limit setting
100%
• Sets the high limit value of OUT2.
• Not available if the DT option is not added or if OUT2 is in ON/OFF action
• Setting range: OUT2 low limit value to 100%
OUT2 low limit setting
0%
• Sets the low limit value of OUT2.
• Not available if the DT option is not added or if OUT2 is in ON/OFF action
• Setting range: 0% to OUT2 high limit value
Overlap band/Dead band setting
0
• Sets the overlap band or dead band for OUT1 and OUT2.
+ set value: Dead band, – set value: Overlap band
• Available only when the DT option is added
• Setting range: -100.0 to 100.0 ( ), or -1000 to 1000
OUT2 ON/OFF action hysteresis setting
1.0
• Sets ON/OFF action hysteresis for OUT2.
• Available only when the DT option is added
• Setting range: 0.1 to 100.0 ( ), or 1 to 1000
A1 type selection
No alarm action
• Selects an action type for A1.
Note: If an alarm type is changed, the alarm set value becomes 0 (0.0).
: No alarm action : Process high alarm
: High limit alarm : Process low alarm
: Low limit alarm : High limit alarm with standby
: High/Low limits alarm : Low limit alarm with standby
: High/Low limit range alarm : High/Low limits alarm with standby
A2 type selection
No alarm action
• Selects an action type for A2.
Note: If an alarm type is changed, the alarm set value becomes 0 (0.0).
• Available only when A2 option is added
• Types and action are the same as those of A1 type selection.
A1 action Energized/Deenergized selection
Energized
• Selects Energized/Deenergized for A1.
• Not available if No alarm action is selected during A1 type selection
• : Energized, : Deenergized
