SHOWTEC Creator 1024 - Fixture and Playback Control Areas

9
Creator 1024
Ordercode: 50730
The front panel consists of several areas:
3.2 Fixture area
including 16 <Fixture> buttons, 16 sliders and 6 <Page> buttons.
There are 6 pages of fixtures supporting up to 96 fixtures. The <Attribute/Dimmer> button with 2 LED
indicators can be used to switch the functions of the 16 sliders. When <Attribute> is activated, the sliders
are used to adjust the value of attribute which above the sliders; When <Dimmer> is activated, the sliders
are to adjust the intensity of fixtures.
3.3 Playback area
Including 10 <Swop> buttons, 10 <Flash> buttons, 10 playback sliders, 3 <Page> buttons and 1 <Blackout>
button
