5.4 Fan mode
Fan mode automatically spreads out the values on a selected range of fixtures. If used on pan and tilt,
the result is spreading out “rays” of light beams. The first and last fixtures of the range are affected most,
and the central fixtures are affected least. The amount of fan can be set using the wheels. As with
shapes, the order in which you select the fixtures sets how the fan effect works. The fixtures you select first
and last will be the ones which change most. If you use a group to select the fixtures, the order is that in
which the fixtures in the group were selected when it was created. The fan effect, while normally used on
pan or tilt attributes, can be applied to any attribute.
1) Select fixtures;
2) Select attributes;
3) Press <Fan> in “Function area” (indicator on);
4) Set the amount of fan using the wheels;
5) Press <Fan> in “Function area” (indicator off) again to close the fan shape mode when you’ve
finished.
5.5 Clear the Programmer
Clear the Programmer:
Press <Clear> in the menu area.
Clear a certain fixture of a certain attribute from the Programmer:
Select a desired fixture. Press <Off> in the function area then <B>[OFF Selected Fixtures] to delete the
fixture from the Programmer; or, press <OFF> then <C>/<D> to delete the attributes of the fixture from
the Programmer.
