21
9.7 Copy a scene
1) Under the first level menu, press a desired <Swop> button;
2) Press another <Swop> button. Then, the scene in the first button is copied into the second one.
9.8 Run chase
Raise a fader, the corresponding scene on the current page will be output. In the starting menu, press a
<Swop> button to output and all other scenes will be closed; Press <Flash>, then, you can flash the
fixtures.
9.9 Connect
When a chase is added to run, it will connect automatically.
If the current connected chase is not the one that you want to connect, you can press <Connect>
then <Swop> to connect.
If you don’t want to connect any chases, then, you can press <Connect> twice to clear all the
connections.
Once the chase are connected, they can be controlled with <Stop>, <Go+> and <Go->. <Go+>
and <Go-> are to c
ontrol th
e playback direction. To stor
e the running speed, pre
ss <Playback
Parameters> then <B>[Save Speed & Dir].
When a new chase is connected, you can use <Wheel A> to control the global speed and <Wheel
B> to control the global slope if the current Programmer is empty; But, if the current Programmer is
with some data, then, you can press <Connect> then <E>[Change Wh A/B Mode] to switch to the
wheel mode, so that you will be able to control the time of the scene. The time under the control of
<Wheel A> and <Wheel
B> is temporary t
ime; To save t
he time, press <Playba
ck Parameters> t
hen
<B> [Save Speed & Dir]. To restore the previous speed, press <Connect> then <E> to clear the
temporary time. One the speed is save, it cannot be restored.
10 Setup
10.1 Manage USB memory
To save and load data.
10.2 Wipe data
To wipe all the data or only the playback data off the controller.
10.3 Select Language
Press <Setup>. The LCD will show “EN/DE/FR”. Press the desire soft key by the LCD to select your language.
10.4 Manager library
To delete or update the fixture library.
