SHOWTEC Phantom 130 Spot - DMX Channel Details (16 Channel Mode)

20
Ordercode: 40073
Phantom 130 Spot
Channel 9 – Prism
0-3
Not functional
4-6
Prism 1 (6-facet circular prism)
7-65
Prism 1clockwise rotation (CW) prism effect from slow to fast
66-123
Prism 1counterclockwise rotation (CCW) prism effect from slow to fast
124-127
Prism 1
128-131
Not functional
132-134
Prism 2 (5-facet linear prism)
135-193
Prism 2 clockwise rotation (CW) prism effect from slow to fast
194-251
Prism 2 counterclockwise rotation (CCW) prism effect from slow to fast
252-255
Prism 2
Channel 10 – Focus
0-255
Continuous adjustment from far to near
Channel 11 – Zoom
0-255
Continuous adjustment from small to big
Channel 12 – Built-in Programs + Sound-controlled Programs
0-7
No Function
8-23
Built-in Program 1
24-39
Built-in Program 2
40-55
Built-in Program 3
56-71
Built-in Program 4
72-87
Built-in Program 5
88-103
Built-in Program 6
104-119
Built-in Program 7
120-135
Built-in Program 8
136-151
Sound-controlled Program 1
152-167
Sound-controlled Program 2
168-183
Sound-controlled Program 3
184-199
Sound-controlled Program 4
200-215
Sound-controlled Program 5
216-231
Sound-controlled Program 6
232-247
Sound-controlled Program 7
248-255
Sound-controlled Program 8
16 Channels
Channel 1 – Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 – Pan fine 16 bit
Channel 4 – Tilt fine 16 bit
Channel 5 – PAN/TILT Speed
0-255
From Max Speed (0) to Min. Speed (255)
