7
Ordercode: 40073
Phantom 130 Spot
Description of the device
Features
The Phantom 130 Spot is a moving head with high output and great effects.
● Input voltage: 100-240V AC, 50/60Hz
● Power consumption: 270W
● Light source: 1 x 130W White LED
● Light output: 5200 Lux @ 5 m (at 12°)
● Dimmer: 0-100%
● Strobe: 0-20Hz
● Beam angle: 12° - 21°
● Focus: Motorized focus
● DMX control: via standard DMX controller
● DMX channels: 12, 16 channels
● Built-in automatic programs + built-in sound-activated programs
● Reverse Pan / Tilt movement
● Special: Pan / Tilt movement blackout
● Pan 0º -- 540º, Tilt 0º -- 270º
● Pan/Tilt resolution: 16 bit
● Control: Stand alone, Manual, Sound-controlled, Master/Slave, DMX-512
● Color wheel: 7 dichroic colors + white
● Rotating gobo wheel: 6 metal gobos + 1 glass gobo
● Gobo size:
Glass gobo: 23,75 mm (gobo size); 21 mm (image diameter); 1,31 mm (gobo thickness)
Metal gobo: 24 mm (gobo size); 20 mm (image diameter); 0,5 mm (gobo thickness)
● Static gobo wheel: 7 gobos
● Color functions: Split colors, Rainbow-flow effect
● Gobo functions: Gobo-flow effect, Gobo shake
● Rotation: Bi-directional
● Prism: 5-facet linear prism + 6-facet circular prism
● Housing: Metal & flame-retardant plastic
● Connection: 3-pin XLR IN/OUT, Pro power connector IN/OUT
● Fuse: F5AL/250V
● Dimensions: 330 x 210 x 460 mm (LxWxH)
● Weight: 13,1 kg
Frontside
Fig. 01
01) 1 x 130W White LED
02) LCD display + control buttons
