SHOWTEC Phantom 130 Spot - Product Specifications Summary

29
Ordercode: 40073
Phantom 130 Spot
Product Specifications
Model:
Showtec Phantom 130 Spot
Input voltage:
100-240V AC, 50/60Hz
Power consumption:
270W (full output)
DMX linking:
30pcs
Fuse:
F5AL/250V
Dimensions:
330 x 210 x 460 mm (LxWxH)
Weight:
13,1 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+)
DMX Mode:
12, 16 channels
Signal input:
3-pin XLR IN
Signal output:
3-pin XLR OUT
Electro-mechanical effects:
Light source:
1 x 130W White LED
Light output:
5200 Lux @ 5 m (at 12°)
Focus:
Motorized
Beam angle:
12º - 21º
Dimmer:
0-100%
Strobe:
0-20Hz
Housing:
Metal & flame-retardant plastic
DMX control:
via standard DMX controller
Onboard:
LCD display for easy setup
User-selectable Pan range:
540°/360°/180°
User-selectable Tilt range:
270°/180°/90°
Special:
Pan/Tilt movement blackout
Reverse Pan/Tilt movement
Pan/Tilt resolution:
16 bit
Color wheel:
7 dichroic colors + white
Color functions:
Rainbow-flow effect, split colors, bi-directional rotation
Rotating gobo wheel:
6 metal gobos + 1 glass gobo
Gobo size:
Glass gobo:
23,75 mm (gobo size); 21 mm (image diameter); 1,31 mm (gobo thickness)
Metal gobo:
24 mm (gobo size); 20 mm (image diameter); 0,5 mm (gobo thickness)
Static gobo wheel:
7 gobos
Gobo functions:
Gobo-flow effect, Gobo shake
Control:
Stand alone, Manual, Sound-controlled, Master/Slave, DMX-512
Prism:
5-facet linear prism + 6-facet circular prism
Connections:
3-pin XLR IN/OUT, Pro power connector IN/OUT
Cooling:
Cooling fan
Max. ambient temperature t
a
:
40°C
Max. housing temperature t
B
:
70°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m
Design and product specifications are subject to change without prior notice.
