Shure Incorporated
40/76
2. Under the Button Properties menu, change the Mute Control Function setting to Logic out.
MXA310 MicroflexAdvance Command Strings
The device is connected via Ethernet to a control system, such as AMX, Crestron or Extron.
Connection: Ethernet (TCP/IP; select “Client” in the AMX/Crestron program)
Port: 2202
Conventions
The device has 4 types of strings:
GET Finds the status of a parameter. After the AMX/Crestron sends a GET command,
the MXA310 responds with a REPORT string
SET Changes the status of a parameter. After the AMX/Crestron sends a SET com
mand, the MXA310 will respond with a REPORT string to indicate the new value of
the parameter.
REP When the MXA310 receives a GET or SET command, it will reply with a REPORT
command to indicate the status of the parameter. REPORT is also sent by the
MXA310 when a parameter is changed on the MXA310 or through the GUI.
SAMPLE Used for metering audio levels.
All messages sent and received are ASCII. Note that the level indicators and gain indicators are also in ASCII
Most parameters will send a REPORT command when they change. Thus, it is not necessary to constantly query
parameters. The MXA310 will send a REPORT command when any of these parameters change.
The character
“x”
in all of the following strings represents the channel of the MXA310 and can be ASCII numbers 0 through 5 as in
the following table.
0 All channels
1 through 4 Individual channels
5 Automix output
Command Strings (Common)
Get All
