Command String:
< SET x CHAN_LED_IN_STATE ON >
< SET x CHAN_LED_IN_STATE OFF >
Where x is ASCII channel number: 1
through 4. Send one of these com
mands to the MXA310. This com
mand is only available when both
“Mute Control Function” is set to
“Logic Out” or "Disabled" AND Light
Ring “Lighting Style” is set to “Seg
ments” in the GUI.
MXA310 Response:
< REP x CHAN_LED_IN_STATE ON >
< REP x CHAN_LED_IN_STATE OFF >
The MXA310 will respond with one
of these strings.
Get LED Brightness
Command String:
< GET LED_BRIGHTNESS >
MXA310 Response:
< REP LED_BRIGHTNESS n >
Where n can take on the following
values:
0 = LED disabled
1 = LED dim
2 = LED default
Firmware > v3.0:
0 = LED disabled
1 = 20%
2 = 40%
3 = 60%
4 = 80%
5 = 100%
Set LED Brightness
