• Perform a Scan and Sync to ensure the transmitter and receiver are set
to the same channel or frequency
• Look at the label on the transmitter and receiver to make sure they are
in the same band (G50, J50, L50, etc...).
Reducing Interference
• Perform a scan to find the best open frequency. Perform an IR sync to
transfer the settings to the transmitter.
• For multiple systems, make sure that each receiver is assigned to a
unique channel. Interference will occur if two transmitters are set to the
same channel.
• Maintain a line of sight between transmitter and receiver antennas.
• Move receiver antennas away from metal objects or other sources of RF
interference (such as CD players, computers, digital effects, network
switches, network cables and Personal Stereo Monitor (PSM) wireless
systems).
• Eliminate RF overload (see below).
Increasing Range
• Increase transmitter RF power level to Hi
• Use an active directional antenna, antenna distribution system, or other
antenna accessory to increase RF range
Eliminating RF Overload
If the RF OL icon appears on the RF meter, try the following:
• Reduce the transmitter RF power level from Hi to Lo
• Move the transmitter further away from the receiver—at least 6 m (20 ft)
• If you are using active antennas, reduce antenna or amplifier gain.
• Use omnidirectional antennas
Error Codes and Solutions
Error codes are generated when the receiver detects a condition that can
potentially affect system performance.
If an error is displayed on the receiver, use the following table to identify the
problem and find the corresponding solution.
SolutionsDescription
Error
Code
Update transmitter and receiver firmware
to the latest version.
Audio Compatibility
Err.001
Set encryption to off for components from
different Shure products lines, such as
QLX-D and ULX-D.
Encryption Mismatch
between Shure product
lines
Err.002
Perform an IR sync between the
transmitter and receiver to clear the error.
Encryption Mode
Mismatch
Err.003
Receiver and transmitter are operating in
overlapping frequencies from different
bands.
Band Mismatch
Err.004
Receiver and transmitter are from bands
that do not share compatible frequencies.
Frequency Mismatch
Err.005
Rescan, select a different group, or use
WWB to find a frequency.
No Frequencies Found
Err.006
Update firmware on the transmitter and
receiver.
Firmware Mismatch
Err.007
Check that battery is firmly installed into
the battery compartment. If condition
persists, replace the battery.
Shure SB900 battery
runtime does not
appear on display
Err.008
To complete the firmware update, match
the type of transmitter to the type of
firmware the receiver currently has.
•HH BP = handheld or bodypack
firmware
•BN GN = gooseneck or boundary
firmware
Transmitter Type
Mismatch
Err.009
Shure IncorporatedQLX-D Wireless System
25/342017/10/04

Shure QLXD2 Specifications

General

RF power	1.1 mW
Form factor	Handheld transmitter
Antenna type	Built-in
Display type	LCD
Compatibility	Shure QLXD4 Digital Wireless Receiver
Product color	Black
Average latency	2.9 ms
Built-in display	Yes
Housing material	Metal
Security algorithms	256-bit AES
Maximum outdoor range	100 m
Operating frequency type	Ultra High Frequency (UHF)
Radio Frequency (RF) range	606 - 670 MHz
Operating temperature (T-T)	18 - 50 °C
Microphone frequency response	30 - 20000 Hz
Total Harmonic Distortion (THD)	0.1 %

Weight and Dimensions

Width	51 mm
Height	256 mm
Weight	347 g
