Shuttle MV43V - Jumpers & Connectors Guide

- 24 -
Jumpers & Connectors Guide
Use the mainboard layout on page 11 to locate CPU socket, memory banks,
expansion slots, jumpers and connectors on the mainboard during the instal-
lation. The following list will help you to identify jumpers, slots, and connec-
tors along with their assigned functions:
CPU/Memory/Expansion Slots
Socket478 : CPU Socket for Pentium 4 processors
DDR1/2 : Two DIMM Slots for 64, 128, 256, 512 MB, and
1GB of 2.5V DDR SDRAM
(The total installed memory does not exceed 2GB)
AGP : One AGP (Accelerated Graphics Port) Slot
PCI : Two 32-bit PCI Expansion Slots
CNR : Communication Network Riser slot
B2~B4
B5
B6~B7
B1
E5
C5
C6
E1
E3
C1~C4
E2
E2
D1
A1
A3
A2
D1
B8~B10
E4
