- 28 -

Keyboard Power On(JP2)

This jumper enables any keyboard activity to power up a system

which is previously in a standby or sleep state.

Disabled

Short Pins 1-2 (5V)

Enabled

Short Pins 2-3 (5VSB)

JP2
