Shuttle MV43V - Jumpers

- 25 -
Jumpers
JBAT1 : Clear CMOS setting
JP1A1/JP1B1 : CPU Clock setting
JP2 : Keyboard Power On setting
Back Panel Connectors
KB : PS/2 keyboard port
MS : PS/2 mouse port
PRINTER : Parallel port (DB25 female)
COM1 : Serial port 1
VGA : VGA Port
USB : 2 USB (Universal Serial Bus) ports
LAN : RJ45 LAN Port (MV43VN Only)
USB : 2 USB (Universal Serial Bus) ports
LINE-IN : Line-In Port
LINE-Out : Line-Out Port
MIC-IN : Mic-In Port
Front Panel Connectors
HD_LED : IDE drive active LED
SP_ LED : Green LED
RST : Hardware reset switch
PW_BN : ATX power on/off momentary type switch
SPK1 : Speaker Connector
USB2 : Extcnded USB Header
Internal Peripherals Connectors
FDC : Floppy disk drive interface
IDE1 : IDE primary interface (Dual-channel)
IDE2 : IDE secondary interface (Dual-channel)
A1
A2
A3
B1
B2
B3
B4
B1
B5
B6
B7
B8
B9
B10
C1
C2
C3
C4
C5
C6
D1
D1
D1
