Rotary Rudder Feedback Installation
If you have purchased a SP-70 or SP-80 with an Outboard Feedback, please see the instructions
titled, "Outboard Feedback".
Select the following parts from your SP-70 or SP-80 package:
You may also need:
•
One stai
nless steel band clamp to hold the Rudder Arm to the rudder post.
• Four screws: #10 size (5 mm), suitable length.
Install the Rudder Feedback Assembly in the stern of the vessel, close to the rudder post. Place
the Rudder Feedback so that it will be protected from objects which may shift position when your
boat is moving.
RUDDER FEEDBACK
LINKAGE
BRASS BALL JOINT
(INCLUDED WITH LINKAGE)
