Operation Commands cont.
Dodge: left In PILOT or NAV MODE.
Press and hold Red Key.
Display will show:
x x x d
Release Red Key to return to
PILOT or NAV MODE.
Vessel turns left.
When key is released P
ILOT
display returns and vessel returns
to original course.
Dodge: right In P
ILOT or NAV MODE.
Press and hold Green Key.
Display will show:
x x x d
Release Red Key to return to
PILOT or NAV MODE.
Vessel turns right.
When key released P
ILOT display
returns and vessel returns to
original course.
Rudder response: change In P
ILOT MODE.
Press Set Key once.
Display will show either:
F A S t
or
S L O U
Press Red or Green Key.
Autopilot will switch to the other set
of rudder response adjustments.
Steer by Loran, GPS or
plotter.
Select Waypoint. Press Nav
Key.
Display will show [xxxn]
Pilot will steer by compass and
NMEA data received. If no NMEA
data received, pilot will remain in
NAV mode but will steer by
compass.
Dim or brighten lights on
Control Unit.
In S
TANDBY.
Press Set Key once.
Press Green Key to increase
or Red Key to decrease
brightness.
Control Unit’s backlight will move
through eight levels of brightness.
Change from compass
display to permanent rudder
angle display.
In P
OWER STEER MODE, press
the Set Key.
The SP-70 or SP-80 will constantly
display the rudder angle while in
S
TANDBY. Pressing the Set Key
again will return to the compass
display.
