CLV61x BAR CODE SCANNERS
Product description
The CLV61x product family consists of
compact, powerful bar code scanners.
In order to offer the best solution for the
application, different versions are avail-
able (CAN, Fieldbus). The CLV615 Field-
bus version was developed specically
for the requirements of intralogistics.
Thanks to the optimized reading eld for
container identication on the conveyor
belt, in combination with the intuitive
SOPAS user interface, quick and easy
integration into your conveyor system is
possible. The optional connectors, e. g.,
CDF600-2, enable simple connection
to your control system, as well as direct
conguration from the control environ-
ment. Thanks to the optional congura-
tion cloning module, rapid scanner re-
placement is also possible in the event
of a fault – without having to recongure
via laptop/PC.
At a glance
• Optimized reading eld for intralogis-
tics applications
• Available with SICK CAN sensor
network
• Conguration with SOPAS, the
conguration tool for all new SICK
products
• Available in different versions (CAN,
Fieldbus) for use in almost any ap-
plication
• Adjustable scanning frequency of up
to 1000 scans/second
• Compact design
Your benets
• A suitable scanner version for any
CLV61x application
• An optimized reading eld for con-
tainer identication on a conveyor
belt, in combination with the intuitive
SOPAS user interface, enables quick
and easy integration into your con-
veyor system
• Compact design enables installa-
tion even in applications with limited
space
• Less programming time required for
the control system, since data can be
transmitted to the control system in
the desired format
• Depending on the version, the
CLV61x bar code scanner can be
used as a multiplexer in any SICK
CAN sensor network, so additional
multiplexers are not required
• The optional conguration cloning
module in combination with the
quick-release mounting bracket
enables very fast replacement time in
the event of a fault
CLV6 series
BAR CODE SCANNERS
CLV61x
Subject to change without notice
.
Reliable DecoDing,
Simple integRation
Additional information
Detailed technical data . . . . . . . . . . 19
Ordering information . . . . . . . . . . . . 20
Dimensional drawings . . . . . . . . . . . .21
Reading eld diagrams . . . . . . . . . . 22
Recommended accessories . . . . . . 23
- www.mysick.com/en/CLV61x
For more information, just enter the link or scan the QR code and get direct access to technical
data, CAD design models, operating instructions, software, application examples and much
more.
