SICK CLV6 Series User Manual

CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
20
CLV61x BAR CODE SCANNERS
Mechanics/electronics
CLV610 Mid Range CLV612 Short Range CLV615 Long Range
Electrical connection
1 15-pin D-Sub HD male connector (0.9 m)
Operating voltage
10 V DC ... 30 V DC
Power consumption
2.8 W
Housing
Die-cast aluminum
Housing color
Light blue (RAL 5012)
Enclosure rating
IP 65 (DIN 40 050)
Protection class
III (VDE 0106/IEC 1010-1)
Weight
265 g, with connecting cable 295 g, with connecting cable
Dimensions
61 mm x 66 mm x 38 mm 80 mm x 66 mm x 38 mm
Ambient data
Electromagnetic compatibility (EMC)
EN 61000-6-4 (2007-01) + A1 (2011) / EN 61000-6-2 (2005-08)
Vibration resistance
EN 60068-2-6 (2008-02)
Shock resistance
EN 60068-2-27 (2009-05)
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, non-condensing
Ambient light safety
2,000 lx, on bar code
Bar code print contrast (PCS)
≥ 60 %
Ordering information
• Focus: Fixed focus
• Connection type: cable
• Front screen: Glass
Version Reading eld Scanner design Items supplied Model name Part no.
CLV610 Mid Range Front
Line scanner Single scanner CLV610-C0000 1057125
Raster scanner Single scanner CLV610-C1000 1062846
CLV612 Short Range
Front
Line scanner Single scanner CLV612-C0000 1066271
Raster scanner Single scanner CLV612-C1000 1062861
Side
Line scanner Single scanner CLV612-C2000 1066272
Raster scanner Single scanner CLV612-C3000 1062862
CLV615 Long Range Side Line scanner
Single scanner CLV615-F2000 1058334
Kit including single scanner and eldbus
module PROFIBUS DP (interface 1 x D-Sub,
female connector, 9-pin)
CLV615-
F2000 CDF600-
2100 Kit
1061528
Kit includes single scanner and eldbus
module PROFIBUS DP (interface 2 x M12,
male connector/female connector, 5-pin)
CLV615-
F2000 CDF600-
2103 Kit
1061529
