CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
6
WIDE RANGE OF
MODELS
Designs
Flexible interface concept
• PROFINET, Ethernet/IP, Ethernet TCP/IP, CANopen,
CSN (SICK CAN sensor network), and serial communication
on board
• PROFIBUS DP, PROFINET IO Dual Port, EtherCAT, and other
interfaces via external gateways with eldbus proxies
Front reading window Side reading window, light emission be-
low 105°
Side reading window with oscillating mirror
Please refer to the selection guide on page 16 onwards.
More information on page 14 onwards.
Scanning methods
Line scanner – for reading in
tilted positions
Raster scanner – for reading codes
redundantly
Oscillating mirror – for reading on large surfaces
VERSIONS WITHIN THE CLV6 SERIES
Uniform conguration concept
All CLV6xx products have a user-friendly conguration system
based on SOPAS ET. This uniform, cross-sensor operating
system from SICK means users can quickly nd their way
around without the need for time-consuming training. This also
provides exible adjustment options for the output format. The
sorting and ltering function incorporated into SOPAS saves
PLC programming.
Statistics function
The CLV62x to CLV65x also offer an integrated statistics
function, which can be visualized via a user-friendly web
server. If required, the SICK visualization platform (SVP) can be
accessed. This includes a high-performance information and
image management platform for performance control, which is
used with SICK data recording systems in sorting tasks.
Oscillating
Mirror
