CLV6 SERIES | SICK8016144/2013-09-19
Subject to change without notice
9
SMART (code reconstruction)
Reliable reading of even damaged, dirty, and/or partially covered bar
codes. Reliable reading even in tilted positions. This means that the bar
code can be attached in a position that is rotated up to 45 degrees in
relation to the scanning beam.
microSD memory card
Integrated function buttons
Commissioning without a PC by simply teaching in directly on the device
via the function buttons.
Range of focus types
Fixed focus, dynamic focus, and auto-focus.
Line scanner and/or raster scanner
Choose from a line scanner with a simple working area and a raster
scanner with an extended working area.
Oscillating mirror version and designs with side reading
windows
Industry-tested IP 65 housing
Integrated event monitor
Analysis tool for commissioning support.
Remote monitoring with integrated web server
For monitoring the reading rate.
Auto-setup
For fast commissioning.
Swivel connector
Exceptionally simple mounting thanks to the swivel connector and the
SPEEDCON thread. As a result, the scanner can be integrated easily into
your network, even under difcult installation conditions.
Flexible interface concept
PROFINET IO, Ethernet/IP, Ethernet TCP/IP, CANopen, SICK CAN sensor
network, and serial communication on board. PROFIBUS DP and additional
eldbus connection via external CDF600-2 eldbus modules.
Cable or male connector
CLV63x to CLV65x are available as cable and male connector versions.
SIMPLE MOUNTING AND FIELDBUS CONNECTION
CLV63x to CLV65x
CLV63x ............ Page 32
CLV64x ............ Page 42
CLV65x ............ Page 50
PRODUCT DETAILS
SMART
Micro SD
Card
Fixed Focus
Dyn. Focus
Auto Focus
