CLV63x BAR CODE SCANNERS
Product description
The CLV63x series of bar code scanners
are compact, powerful tools satisfying
the needs of a wide range of applica-
tions and industries. Newly improved
SMART algorithms in the CLV63x are
superior when reading damaged and
tilted codes. In addition, pushbuttons
on the CLV63x and above allow for quick
bar code setup without using a comput-
er. Match code teach-in and diagnostic
triggering are also possible. In addi-
tion to the LED bar graph, the CLV63x
has other LED indicators on its body
that show communication and scanner
performance. The microSD memory card
slot allows users to easily clone scanner
parameters. Variants include line, raster,
side reading window and oscillating mir-
ror versions; available with Ethernet.
At a glance
• Integrated pushbuttons for auto
setup and reading diagnostics
• Integrated LED bar graph
• CAN, Ethernet TCP/IP, PROFINET, and
EtherNet/IP available on board, no
additional gateway needed (depend-
ing on variant)
• Enhanced SMART code reconstruc-
tion technology
• Flexible sorting, ltering, and logical
functions
• Advanced, easy-to-use SOPAS con-
guration software
• High scanning frequency of up to
1,200 Hz
• Advanced remote diagnostics and
network monitoring capabilities avail-
able over Ethernet
Your benets
• Intelligent auto setup and multi-func-
tion pushbuttons save time during
commissioning
• Easily execute rmware updates
using the microSD memory card: no
need for a PC
• Enhanced SMART technology reads
damaged and partially obscured
codes, increasing read rates
• Increased scanner intelligence
enables sophisticated conguration
of logical operations, reducing the
control system programming effort.
Data is then delivered in the desired
format
• Real-time decoding at very high
speeds
• Increased reading reliability due to
high-performance computing power
and a high scanning frequency
CLV63x
IntellIgent scannIng solutIon for
logIstIcs and automatIon
Additional information
Detailed technical data . . . . . . . . . . 33
Ordering information . . . . . . . . . . . . 35
Dimensional drawings . . . . . . . . . . . 36
Reading eld diagrams . . . . . . . . . . .37
Recommended accessories . . . . . . 40
2011/65/EU
- www.mysick.com/en/CLV63x
For more information, just enter the link or scan the QR code and get direct access to technical
data, CAD design models, operating instructions, software, application examples and much
more.
