SICK CLV6 Series - Reading field diagrams

CLV6 SERIES | SICK8016144/2013-09-19
Subject to change without notice
37
BAR CODE SCANNERS CLV63x
CLV63x/64x Ethernet, side
CLV63x/64x/65x, Ethernet, oscillating mirror
Reading eld diagrams
CLV630 Long Range, front
800
(31.5)
600
(23.62)
400
(15.75)
200
(7.87)
0
Reading distance in mm (inch
)
Resolution
a: 0.35 mm (13.8 mil)
c: 1.0 mm (39.4 mil)
b: 0.50 mm (19.7 mil)
–400
(–15.75)
–300
(–11.81)
–200
(–7.87)
–100
(–3.94)
100
(3.94)
200
(7.87)
300
(11.81)
400
(15.75)
0
Reading field height in mm (inch)
a
b
c
CLV630 Long Range, side
800
(31.5)
600
(23.62)
400
(15.75)
200
(7.87)
0
Reading distance in mm (inch
)
Resolution
a: 0.35 mm (13.8 mil)
c: 1.0 mm (39.4 mil)
b: 0.50 mm (19.7 mil)
–400
(–15.75)
–300
(–11.81)
–200
(–7.87)
–100
(–3.94)
100
(3.94)
200
(7.87)
300
(11.81)
400
(15.75)
0
Reading field height in mm (inch)
a
b
c
