BAR CODE SCANNERS CLV63x
Detailed technical data
Features
CLV630 Long Range CLV631 Mid Range CLV632 Short Range
Light source
Visible red light (655 nm)
MTBF
40,000 h
Laser class
2 (EN 60825-1 (A2:2001-03), IEC 60825-1 : 2007-03, Ed. 2.0)
Field of view
≤ 50°
Scanning frequency
400 Hz ... 1,200 Hz
Code resolution
0.35 mm ... 1 mm 0.25 mm ... 0.5 mm 0.2 mm ... 0.5 mm
Reading distance (at code resolution)
Front 60 mm ... 735 mm (1 mm) 90 mm ... 450 mm (0.5 mm) 60 mm ... 285 mm (0.5 mm)
Side 44 mm ... 683 mm (1 mm) 74 mm ... 412 mm (0.5 mm) 44 mm ... 256 mm (0.5 mm)
Oscillating mirror 45 mm ... 659 mm (1 mm) 78 mm ... 397 mm (0.5 mm) 45 mm ... 245 mm (0.5 mm)
Raster height, number of lines, at distance
15 mm, 8, 200 mm
15 mm, 8, 185 mm
(depending on type)
Oscillating mirror functions
Fixed (adjustable position), oscillating (variable or xed amplitude), one shot
Oscillation frequency 0.5 Hz ... 6.25 Hz
Angle of deection –20° ... 20°
Performance
Bar code types
All current code types, Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128,
UPC / GTIN / EAN, Interleaved 2 of 5, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio
2:1 ... 3:1
No. of codes per scan
1 ... 20 (Standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading interval
1 ... 50 (auto-discriminating)
No. of characters per reading interval
5,000
500 (for multiplexer function in CAN operation)
No. of multiple readings
1 ... 99
Interfaces
CLV630 Long Range CLV631 Mid Range CLV632 Short Range
Serial (RS-232, RS-422/485)
l, AUX (only RS-232)
Function Host, AUX
Data transmission rate 2,400 Baud ... 115 kBaud, AUX: 57.6 kBaud
Ethernet
– / l (depending on type)
Function Host, AUX
Data transmission rate 10/100 Mbit
Protocol TCP/IP, EtherNet/IP, PROFINET, PROFINET Dual Port (optional via external connection module
CDF600-2), EtherCAT (optional via external connection module CDF600)
(depending on type)
CAN bus
l
Function SICK CAN sensor network (Master/Slave, Multiplexer/Server)
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CANopen, CSN (SICK CAN Sensor Network)
PROFIBUS DP
l, optional via external connection module (CDF600-2)
DeviceNet
l, optional via external connection module (CDM + CMF)
