ACCESSORIES CLV6 series
71
Mounting brackets/plates
Brief description Part no.
CLV61x Cable CLV62x Cable CLV62x Ethernet CLV63x-65x Cable CLV63x-65x Ethernet CLV69x
Bracket with adapter board 2042902
O O O
– – –
Mounting bracket (simple bracket) 2020410
O O O O O
–
Hanger-shaped mounting bracket 2042800 – – –
O O
–
Mounting bracket with integrated vibration and shock absorber for mounting the
scanner e.g., on a forklift
2042799 – – –
O O
–
Simple mounting bracket 2013824 – – – – –
O
Mounting bracket with integrated vibration/shock absorption for mounting the scan-
ner on a forklift, for example (mounted in the direction of travel, on the right side)
2039493 – – – – –
O
Mounting bracket with integrated vibration/shock absorption for mounting the scan-
ner on a forklift, for example (mounted in the direction of travel, on the left side)
2017628 – – – – –
O
Articulated mounting bracket, self-locking 2018435 – – – – –
O
Mounting bracket with integrated vibration/shock absorption for mounting the scan-
ner on a forklift, for example (mounted in the direction of travel, on the left side; in
this case, the scanner’s position is rotated by 180 degrees)
2065639 – – – – –
O
Universal clamping bracket for rod mounting 2042802
