Design and function
Teach-in LEDs (continued)
LED Description
Q1 near, Q1 far,
Q2 near, Q2 far,
slow … fast
in expert mode
• “Q1 near” LED lights up and “slow … fast” LED ashes
cyclically: Select function for multifunctional input “MF”.
– 1 x: Teach
– 2 x: Laser o
– 3 x: Inactive
• “Q1 far” LED lights up and “slow … fast” LED ashes
cyclically: Select level for multifunctional input “MF”.
– 1 x: Low active
– 2 x: High active
• DT35 and DL35 models only
"Q2 near" LED lights up and "slow … fast" LED ashes
cyclically: Select Q2 output function.
– 1 x: 4 ... 20 mA
– 2 x: 0 ... 10 V
– 3 x: Switching
Table 4: Teach-in LEDs
Operating pushbuttons
Operating button Description
select (–) • In run mode
Press select pushbutton longer than 5 seconds: Enter or
leave teach mode.
• In teach mode
Press select pushbutton: Select function.
• In ne teach mode
Move previously taught-in switching point by –10 mm.
set (+) • In run mode (IR models only)
Press set pushbutton longer than 5 seconds: Enter or
leave alignment mode.
• In teach mode
Press set pushbutton: Perform teach, select function.
• In ne teach mode
Move previously taught-in switching point by +10 mm.
select + set • In run mode
Press select and set pushbuttons simultaneously for
longer than 10 seconds: Enter or leave expert mode.
• In teach mode
After previously performing teach, press select and set
pushbuttons simultaneously for less than 1 second:
Enter or leave ne teach.
Table 5: Operating pushbuttons
