11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/GLS6
These operating instructions provide additional technical data if required.
11.1
Optics and illumination
Table 14: Technical data: optics and illumination
Device type GLS6
Focus Teach auto focus when teaching-in the working distance using a
configuration tool
1)
LED-integrated illumina‐
tion unit
2 x 2 LEDs, light color combination:
•
Blue (λ = 470 nm ± 15 nm)
•
Red (λ = 617 nm ± 15 nm)
LED risk group:
Risk group 1 (low risk) according to IEC 62471-1: 2006-07/
EN 62471-1: 2008-09.
Radiance:
•
L
B
: < 10 x 10
3
W/(m
2
sr) within 100 s; at a distance of
≥ 200 mm
•
L
R
: < 3.7 x 10
5
W/(m
2
sr) within 10 s; at a distance of
≥ 200 mm
Feedback LED (spot in field
of view)
1 x LED, green (λ = 525 nm ± 15 nm)
LED risk group:
Risk group 0 (no risk) according to IEC 62471-1: 2006-07/
EN 62471-1: 2008-09
MTBF of LEDs (illumination
and feedback)
75,000 h, at ambient operating temperature 25 °C
Aiming laser (2 points in
field of view)
2 x LED, visible light, red (λ = 630 nm ... 680 nm), can be deacti‐
vated
Laser class Class 1 according to EN/IEC 60825-1: 2017. Corresponds to 21
CFR 1040.10 except for tolerances according to Laser Notice 50
from June 24, 2007. P < 0.39 mW per laser module
1)
SOPAS ET configuration software
11.2 Performance
Table 15: Technical data: Performance
Device type GLS6
Working distance 70 mm - 500 mm (Data Matrix code, resolution: 0.7 mm)
Overspeed
1)
5 m/s
Image sensor resolution 1.3 Mpx (1,280 px x 1,024 px)
Image sensor type (color) CMOS matrix sensor, monochrome (black/white)
Image recording rate 1.3 Mpx: 50 Hz
Readable code structures 2D
11 TECHNICAL DATA
48
O P E R A T I N G I N S T R U C T I O N S | GLS6 8024289//2019-08-15 | SICK
Subject to change without notice
