Device type GLS6
2D code types Data Matrix ECC200, QR code
Code quality determination On the basis of ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 15416,
ISO/IEC 18004
Evaluation time ≥ 100 μs
MicroSD memory card Max. 32 GB
1)
The overspeed is dependent on reading distance, alignment and the 2D code used, see "Typical refer‐
ence values during operation", page 53.
11.3 Interfaces
Table 16: Technical data: Interfaces
Device type GLS6
USB
1)
AUX 1 (USB 2.0), for service (e.g. configuration, diagnostics or
image transmission)
CAN Host 1, 20 kBit/s ... 1 MBit/s
Bus length max. 30 m
Protocols:
•
A connection in a CANopen-based environment is possible. For
additional support, please contact SICK customer service.
•
CSN (SICK CAN sensor network)
Ethernet Host 2 (10/100 MBit/s) for data output (read result)
Protocols:
•
TCP/IP
•
EtherNet/IP
AUX 2 (10/100 MBit/s), for service (e.g. configuration, diagnostics
or image transmission)
Protocols:
•
TCP/IP
Services: DHCP, NTP, HTTP, mDNS, DNS-SD. DNS and HTTPS.
MAC address (device-specific), see type label
PROFIBUS Host (RS-232) optionally over external field bus module
CDF600-21xx
2)
to bus (RS-485)
Function blocks for various PLC manufacturers are available online
at: www.sick.com/GLS6
PROFINET (line topology) PROFINET Single Port, PROFINET Dual Port (optional over external
fieldbus module CDF600-21xx
2)
)
Function blocks for various PLC manufacturers are available online
at: www.sick.com/GLS6
EtherCAT® Host (RS-232) optionally over external field bus module
CDF600-0300
2)
(gateway mode) to bus (Ethernet)
Digital outputs 4 x physical
V
out
= V
S
– 1.5 V, I
out
≤ 100 mA (typical)
Short-circuit protected, temperature protected, not electrically iso‐
lated from the supply voltage
Optical indicators 5 RGB LEDs (status display) on top of device
1 x LED bar graph display (blue) on top of device
1 x feedback LED (green) as light area on code
1 x RGB LED (status display for memory card), under hinged cover
Acoustic indicator Beeper (buzzer), can be deactivated
3)
Function for event signaling adjustable
3)
