Device type GLS6
Configuration tools (para‐
meterization)
SOPAS ET configuration software, CoLa commands (telegrams),
fieldbus controller (PLC) with additional support by SICK function
blocks, function buttons
1)
Data interface only for temporary use (service).
2)
Optional accessories.
3)
e.g. with SOPAS ET configuration software.
11.4 Mechanics/electronics
Table 17: Technical data: Mechanics/electronics
Device type GLS6
Electrical connection 1 x male connector, M12, 17-pin, A-coded
1)
1 x female connector, M12, 4-pin, D-coded
1)
1 x female connector, USB, 5-pin, Micro-B type
1 x microSD card slot
Supply voltage V
S
DC 12 V ... 24 V, ± 20%
Voltage source as per ES1 and PS2 or lower (EN62368-1), or as
per SELV (EN60950-1)
Power consumption Operation: 4 W typical
2)
Maximum 22 W with typical loading of the 4 digital outputs with
100 mA each and 28.8 V DC supply voltage
Current consumption Max. 0.8 A with DC 28.8 V
Housing material Die cast aluminum, plastic
Housing color Blue (RAL 5012), black
Viewing window material Plastic (PMMA), 2 mm thick, with scratch-proof coating
Hinged cover (rear of
device)
Plastic. Hinge-open cover
3)
for temporary access to USB interface
and memory card slot. 2 x fixing screws TX6, captive.
Enclosure rating IP 65 (EN 60529, EN 60529/A2)
Protection class III
Electrical safety EN 62368-1
Weight 170 g
Dimensions (L x W x H) 88.5 mm x 43 mm x 35.6 mm
1)
On swivel connector.
2)
For digital outputs without load.
3)
When the flap is open, the device no longer conforms with the specified enclosure rating.
4)
see "Device view", page 14.
11.5 Ambient data
Table 18: Technical data: Ambient data
Device type GLS6
Electromagnetic compati‐
bility (EMC)
Radiated emission: EN 61000-6-4: 2007-01 + A1: 2011-03
Immunity: EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6:2008-02
Shock resistance EN 60068-2-27:2009-05
