Operation Control
Operating Instru
ctions
IDM corded
& IDM Blueto
oth
82
© SICK AG · Germany · All rights reserv
ed · Subject to chang
e without notice
8017159/142O/2019-05-23
3.9.3
Redundancy, 1D Code Inverse Reading
PROGRAM
F_DEFAULT
Family Code Selection
P.C.
Parameter Selection
Option Code
Redundancy
SS
N
one
0
SS
Level 1
1
SS
Level 2
2
SS
Level 3
3
SS
Level 4
4
SS
Level 5
5
The Redundancy is
the number of times the
same barcode
has to be deco
ded befor
e it is trans
mitted.
(To prevent po
tential mi
sreading
.)
1D Barcode Inverse
Reading
SS
Disab
le
0
SS
En
able
1
