Operation Control

Operating Instructions

IDM corded

& IDM Bluetooth

8017159/142O/2019-05-23

3.9.8 Illumination Control, Presentation Background Lighting

PROGRAM

F_DEFAULT

Option Code

Family Code

Selection

P.C. Parameter Selection

1D Corded

(IDM1x0)

2D Corded

(IDM2x0)

1D BT

(IDM1x1)

2D BT

(IDM2x1)

Illumnation Control

SS Disable - 0 - 0

SS Enable  - 1 - 1

Not available for presentation, force and

diagnostic mode

Presentation

Background Lighting

SS LEDs Off - 0 - 0

SS LEDs On  - 1 - 1

Presentation Background Lighting Control: You can enable or disable presentation background lighting of the

scanner according to the ambient light condition in presentation mode. When the ambient light is dim or dark,

you can enable this function to turn on the scanner’s LED illumination at a dim level.
