3 Product description
3.1 Scope of delivery
Depending on the chosen device version, the scope of delivery of the device will include
the following components:
Table 2: Scope of delivery
No. of
units
Component Remarks
1 Type of device ordered (com‐
plete device or basic device)
Complete device:
•
Components are assembled at the factory (cam‐
era housing and optics accessories).
•
Optics protection hood is provided with a device
seal.
Basic device:
•
Mount camera housing and individual compo‐
nents on your own.
•
Order individual components separately as
accessories .
•
Light inlet is sealed with a protective cap.
All devices:
•
Electrical connections are sealed with protective
caps.
•
Without holders and connecting cables
2 Sliding nut, 5.5 mm deep, with
M5 threaded fixing hole
•
Alternative mounting option for the device
instead of the threaded mounting hole
•
Use in pairs.
1 Hexagon key WAF 2
•
S-mount lens: manually adjust focus screw.
•
Open and close foldable cover (access to the
microSD card slot and the focus screw).
2 Blue label (round, self-adhesive)
•
Protection of adjusted focus setting (S-mount
lens)
•
After adjustment of the focus setting, the label
can be stuck over the access opening for the
focus adjustment screw.
•
1 label as spare part
1 SICK lens cloth Clean optical surfaces (e.g. front screen in the
optics protection hood).
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
1)
Depending on order, e.g. lens, integratable VI55I illumination unit, spacers, optics protection hood.
Associated components not contained in the delivery:
Table 3: Other components
Component Remarks
SOPAS ET configuration software Available online at:
•
www.sick.com/SOPAS_ET
This documentation, available in English,
German and French, and in other lan‐
guages if necessary
Available online at:
•
www.sick.com/Lector63x
An overview of available complete devices and a selection guide for the matching
device components for the basic devices is provided on the online product page.
