typically 10°... 20°
Figure 6: Mounting angle to use, depending on the application
1
Typical angle 10° ... 20°
Depending on the application, an angle of 0° (brightfield illumination) or up to 45°
(darkfield illumination) is appropriate.
5 MOUNTING
