Connecting device with connection module
Connection modules Reference
CDB650-204 see "Connection of the device to CDB650-204", page 70
CDM420-0006 see "Connection of the device to CDM420-0006", page 82
NOTE
The operating instructions of the connection modules contains detailed information
on mounting and electrical installation. The operating instructions are available as a
download on the product page of the connection module.
Connection module product page
•
www.sick.com/CDB
•
www.sick.com/CDM
6.5.2 Connecting the supply voltage
The voltage source meets the requirements of ES1 and PS2 (EN 62368-1) or SELV and
LPS (EN 60950-1).
Table 10: Required supply voltage V
S
and power output
Supply voltage V
S
Power source: required power output
1)
DC 12 V ... 24 V ± 20% Maximum 30 W
1)
Valid for device with 4 loaded digital outputs (each 100 mA).
When connecting via the optional CDB or CDM connection module: if the CMC600
cloning module is used, an additional output power of 0.5 W is required.
Table 11: Typical current consumption depending on supply voltage
Designation Supply voltage (V
S
) in [DC V]
9.6
(12 V -20%)
12 24 28.8
(24 V +20%)
Maximum supply current
(2 A fuse)
I
RMS max
1)
[A]
1.5 1.5 1.5 1.5
Current consumption: device
Current consumption, dig‐
ital outputs unloaded,
standby
I
B RMS
[A] 0.58 0.47 0.24 0.21
Current consumption, digi‐
tal outputs unloaded, inte‐
grated illumination unit off
I
B RMS
[A] 0.86 0.68 0.35 0.30
Maximum current con‐
sumption, digital outputs
unloaded, integrated illumi‐
nation unit on
I
B peak
2)
[A] 1.09 0.90 0.45 0.36
Typical, all 4 digital outputs
loaded (0.1 A per output)
I
B RMS 4Out
[A]
1.26 1.08 0.75 0.70
Power loss, integrated illu‐
mination unit on
P
RMS
[W] 8.3 8.2 8.4 8.7
Maximum current consumption: external lighting via connection for external illumination unit
on the device
3)
Current consumption, digi‐
tal outputs unloaded
I
B RMS max
[A] 0.64 0.65 0.65 0.65
ELECTRICAL INSTALLATION 6
