13.2.4 Wiring serial host interface RS-232 of the device in CDB650-204
Device = Lector63x = V2D63xx-xxxxBx
Device 1 CDB650-204 Host
1
.
.
.
TxD
RxD
RxD
TxD
GND
GND
GND
12
1
6
12
6
43
T‒/TxD
44
R‒/RxD
42
GND
6
Shield
RS-232 RS-232
422
485
S6 : RS
ON
OFF
S7: Term 485
S6
422485
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
Cable 2
4 3
Figure 21: Wiring data interface RS-232 of the device in connection module CDB650-204.
1
Device
2
Connection cable 1:1 (female connector, M12, 17-pin, A-coded/male connector, M12, 17-pin, A-coded)
3
Connection module: female connector, M12, 17-pin, A-coded
4
Device: male connector, M12, 17-pin, A-coded
NOTE
Activate the RS-232 data interface in the device with a configuration tool, e.g., the
configuration software SOPAS ET.
13.2.5 Wiring serial host interface RS-422 of the device in CDB650-204
Device = Lector63x = V2D63xx-xxxxBx
ANNEX 13
