Setting the edge direction is only available if edge mode is activated under switching point mode.
8.7.10 Edge offset
Table 36: Edge offset
1
A
|
D9
Edge offset
OK
ESC
Select edge offset using and confirm using OK. After confirmation, the
display returns to the higher-level menu.
1
A
|
12500 μs
D9
Value of the edge offset in micro‐
seconds or milliseconds (depending
on the configured response time).
The value is a multiple (factor 1 ...
255) of the configured response
time.
NOTE
The edge offset specifies the time span of received light values to be compared to determine the edge slope.
Setting the edge offset is only available if edge mode is activated.
8.7.11 Edge hysteresis
Table 37: Edge hysteresis
1
A
|
DA
Edge hyst.
OK
ESC
Select edge hysteresis using and confirm using OK. After confirmation, the
display returns to the higher-level menu.
1
A
|
5
DA
Value of the edge hysteresis in dig‐
its (0 ... 9,999 digits)
NOTE
The edge hysteresis specifies the difference between two edge measuring points below which a switching signal
change does not occur. Setting the edge hysteresis is only available if edge mode is activated.
