8.10.1.1 Analog output mode
Table 57: Analog mode
Analog mode
--------------------------------------------
1
A
|
N1
OK
ESC
Analog output mode
Select analog output mode using and confirm using OK. After confir‐
mation, the display returns to the higher-level menu.
1
A
|
N1
4-20mA
Current based 4-20mA
The analog output supplies a cur‐
rent in the range 4...20mA as
the signal.
1
A
|
N1
0-10V
Voltage based 0-10V
The analog output supplies a
voltage in the range 0...10V as
the signal.
1
A
|
N1
1-5V
Voltage based 1-5V
The analog output supplies a
voltage in the range 1...5V as
the signal.
8.10.1.2 Average filter
Table 58: Average filter
Average filter
--------------------------------------------
1
A
|
N2
OK
ESC
Average value
Select average value using and confirm using OK. After confirmation,
the display returns to the higher-level menu.
1
A
|
N2
64
Average value (number n of indi‐
vidual values in increments of
1/2/4/8/16/32/64/128/256/5
12/1024/2048).
The average is taken from a block of n values. This value is applied
to the output for the next n values until it is replaced by the average
value of the next block of n values, which corresponds to a smooth‐
ing of the analog signal. This number n can be set in increments of
1/2/4/8/16/32/64/128/256/512/1024/2048.
8.10.1.3 Error mode
Table 59: Error mode
Error mode
--------------------------------------------
1
A
|
N3
OK
ESC
Definition of invalid measured values
Select definition of invalid measured values using and confirm using
OK. After confirmation, the display returns to the higher-level menu.
1
A
|
N3
Clamp
Terminals
Sets the output value to
3.5-4.0mA/0V/1V when the
lower threshold of the current or
voltage range is not reached, and
to 20.0-20.5mA/10V/5V
when the upper threshold of
the current or voltage range is
exceeded
1
A
|
N3
Hold
Hold
Sets the output value to the last
valid value within the current or
voltage range before the invalid
state.
