Side-Power SE Series - Electronic Interface Box Wiring Diagram

22
2687
12 2020
-
SE80 & SE100 & SE120 & SE130 & SE150
MG_0036
M
Thermal
switch
Electronic
interface box
6 1232i
A2 A1
4 pin
AMP
connector
On
Motor
4 2 1 3
Fuse
Battery
main
switch
1
5
4
2
6
8
9
red (+)
grey
(sig +)
blue
(sig +)
black (-)
red
grey
(sig -)
blue
(sig -)
brown
3
red
Fused
inside
1A
black
7
white
NB! Make sure to not use
any electronic interface
box (delay box) older than
the 6 1232i (ex. 6 122x)
on SP75Ti, SP95Ti, and
SP125Ti.
NB! Make sure to not use
any electronic interface
box (delay box) older than
the 6 1232i (ex. 6 122x)
