8 Further settings
Pos: 37 /Siebert/B edienungsanlei tungen/Seri e S102/SX102/ Weitere Einstellunge n/S102 W eitere Einstellung en PFN RT @ 4 \mod_1485 177224794_48. docx @ 26962 @ @ 1
With the previous steps, the display shows the sent values with their default settings (factory settings).
In the numeric mode (INT32 format) these settings can be changed by changing the initialization
values. These are transferred once to the display during connection setup via PROFINET.
The following setting options are available by changing the initialization values, see chapter setting the
display settings during initialization (numeric operation mode only):
Number and position of the decimal points
Offset, scale factor (multiplier), and divisor for the conversion formula of the numerical value
Upper and lower thresholds for automatically changing the display mode
Luminosity of the LEDs
Blinking in different modes when thresholds are exceeded or fallen below
Lowering or raising the LED brightness when exceeding or falling below the thresholds
Position of the displayed value
Number of leading zeros
In addition, the S102 series offers the possibility - in both operation modes (INT32 and ASCII format) -
to change all previously mentioned settings as well as the setting of the basic brightness (LED
brightness) in 16 steps during normal operation (see chapter setting of the display mode in normal
operation mode).
