Flags
11 Flags
Pos: 52 /Siebert/B edienungsanlei tungen/Seri e S102/SX102/Fl ags/S102 Flags PFN RT @ 4\ mod_148518 6833733_48.doc x @ 27094 @ @ 1
INT16 flags are to set specific display properties. In the delivery state, the flags are set to 16 # 00F6,
corresponding to 246 decimal.
Bit numbers
Default valuest
Meaning
0
0
Leading zeros (0 = off, 1 = on)
Leading zeros are automatically displayed.
1 + 2 = 00
Only with activated Smart-Dot-Function:
The decimal places are cut off.
1 + 2 = 10
Only with activated Smart-Dot-Function:
The decimal places are rounded.
1 + 2 = 01
Only with activated Smart-Dot-Function:
The decimal places are rounded off.
1 + 2 = 11
11
Only with activated Smart-Dot-Function:
The decimal places are rounded off commercially.
3
0
Smart-Dot-Function (0 = off, 1 = on)
When the Smart-Dot-Function is activated, the display automatically
moves the decimal point so that the decimal value is displayed
completely when the value exceeds the maximum display capacity..
4
1
Invalid initial vale (0 = off, 1 = on)
An invalid initial value is signalized by 3 horizontal lines at each
position.
5
1
Overflow (0 = off, 1 = on)
The value sent tot he display can not be displayed on the display.
6
1
Underflow (0 = off, 1 = on)
The value sent to the display can not be displayed on the display.
7
1
Circumferential frame (0 = off, 1 = on)
Until user data is received for the first time the display alternately
displays a frame or various status messages on its display.
8
0
Output of the number in decimal resp. hexadecimal form.
(0 = decimal, 1 = hexadecimal)
9…15
0
Without function. The bits are to be set to '0'.
