12 Setting the display mode in normal operation
Pos: 55 /Siebert/B edienungsanlei tungen/Seri e S102/SX102/Einst ellung der Darst ellungsart i m normalen Betri eb/S102 Einst ellung der D arstellungsart im n ormalen Betrie b PFN RT @ 4\ mod_148518 8530258_48.d ocx @ 27107 @ @ 1
The settings defined in chapter 'Setting the display settings during initialization' are defined in the
engineering tool in initialization parameters and sent to the display once during the initialization of
PROFINET. These settings can not be changed during normal operation.
The displays of the series S102 also allow to change these parameters during normal operation. Up to
four 'generic property value modules' can be added.
A property number is be assigned to each of these modules. The display then shows the information
sent via this module via PROFINET on the desired parameter.
Pos: 56 /Siebert/B edienungsanlei tungen/Seri e S102/SX102/Ei nstellung der D arstellungsart i m normalen Betri eb/S102 Einst ellung der Grun dhelligkeit (Leuch tstärke der LEDS) PFN RT @ 4\mod_14 85189397017 _48.docx @ 27113 @ 2 @ 1
Setting the basic brightness (luminousity of the LEDs)
The basic brightness of the display is controlled with the following 'global properties':
Global property number
Meaning
Allowed values
0
Blanking of the display
0 = Display is dark
all others: display lights (default)
1
Select luminosity value
0 = Standard luminosity (default)
1 = Out of range luminosity
2
Standard luminosity
0 = off
:
8 = middle luminosity (default)
:
15 = maximum luminosity
3
'out of range'-luminosity
0 = off
:
8 = middle luminosity (default)
:
15 = maximum luminosity
Example: To darken the display at any time via the PLC the module 'generic property value (Integer8)'
is added. The property-group 'global properties' and the property number '0' are set in the engineering
tool in the initialization parameters of this module.
During operation, a number is transferred to this module during cyclic data transmission. If this number
is set to '0', the display will be dark. During darkness, the decimal point of the least significant decade
flashes. As soon as a value other than '0' is transmitted, the display switches its display on.
Pos: 57 /Siebert/B edienungsanlei tungen/Seri e S102/SX102/Einst ellung der Darst ellungsart i m normalen Betri eb/S102 Einst ellung der D arstellungsarten PFN R T @ 4\ mod_1485190 512694_48.docx @ 27120 @ 2 @ 1
Instellung der
