Setting of the display modes
With these setting options, the representation of the number which is transmitted cyclically via
PROFINET is influenced. To control a specific property, a 'generic property value module' is added.
In the parameters of this module, in the Property-group the property 'Property of display field' is
selected and in the field 'Property-number the desired property is entered in the 'Property number'
field.
The description of the properties can be found in chapter Setting the display mode during initialization
(numeric mode only).
Property of display field number
Property
Operation mode
1
Decimal Dots
numeric (INT32)
2
Offset
numeric (INT32)
3
Scale Factor
numeric (INT32)
4
Range – Upper bound
numeric (INT32)
5
Range – Lower bound
numeric (INT32)
6
Flags
numeric (INT32)
7
Standard-attribute
numeric (INT32)
8
Text-atrribute
alphanumeric (ASCII)
9
out of range-attribute
numeric (INT32)
10
Format – Minimum number of digits
numeric (INT32)
11
Format – Minimum width
numeric (INT32)
12
Divisor
numeric (INT32)
